 EVO ARC 160 PFC Inverter
c/w Case, Welding Leads & USB Operating Manual
Order Code: EA-160

List Price: £500

Discount available from your local dealer

eco 160 mma copy.png

Key Features

• Rugged, ergonomic design

• ClearVision technology
• Intelligent synergic control

• Smart Lift TIG

• Adaptable wide voltage range
• Quick factory reset
• Anti-stick, adjustable hot start and arc force
• Dedicated wireless remote control (optional)
• Remote control receiver module (optional)
• Power factor correction (PFC), generator friendly

• ABAP: Active Balancing Air Passage
• Fan on demand
• Voltage Reduction Device (VRD)
• Key power electronic component protection
• Overcurrent and overheat protection
• Complete with protective case and MMA leads

Industrial Design Highlights


Lateral Plate

Detachable for easy servicing, reinforced for enhancing the structures impact strength.

Front Grill

A sloped front grill offers a perfect balance between heat dissipation and ingress protection (IP23S).

Overall Look

Rugged, robust and industrial.

Control Panel

Slanted 45° angle for enhanced visibility and viewing comfort.

Streamlined Handle

Elevates overall aesthetics of the power source and provides a comfortable, firm and glove-friendly grip.

 Advanced MMA Features


This machine features Anti-Stick technology, as well as adjustable Arc Force and Hot Start functionality. These features are designed for improving weld quality and ease of use.

Voltage Reduction Device

VRD ICON.jpg

In MMA (Stick) mode VRD reduces the open-circuit voltage of the inverter.

When the welding machine is on, but not being used

(like when you’ve just finished an electrode and need to grab a new one), the VRD kicks in and lowers the voltage to a safer level (usually around 13V).

Wide Voltage Adaptation

95

wide voltage orange.png

265

50/60 Hz

Compatible with input power sources of AC 95-265 volts.

 Power Factor Correction (PFC)


Improves overall energy efficiency and allows use with AVR generators.

Overheat & Overcurrent Protection

Temp Indicator.jpg

The overheat warning light indicates that the machine has entered overheat protection and stops the welding output, the machine will re-activate once the unit has cooled down.

voltage indicator.jpg

The overcurrent warning light indicates that the machine has entered over-current protection and stops the output. The machine can be reset  by turning off and then back on.

Quick Factory Reset

hand button.png
button press.png

Quick reset to the factory programmed settings in the
event of the operator selecting an incorrect setting.

ux logo white.png

Optional Accessories

EVO Handheld Remote Control

(Wired)

Order Code: HRC-04


EVO Micro Handheld Remote Control

(Wireless)

Order Code: HRC-03

EVO Inverter Trolley

Order Code: JIT-01

JIT-O1 TROLLEY.png
ARC TOP.png

On Demand

Fan

Energy Saving Environment

Friendly

50/60 Hertz

Input Power

Source

ARC BOTTOM.png

Intelligent

Synergic

Control

Wide Voltage

Adaptation

Power Factor

Correction

PFC

HD digital panel providing crisp and clear reading, visible under direct sunlight.

arc160pfc pan.png

With 45° slanted angle for improved visibility and a 41% enhanced

viewing area compared to a vertically positioned control panel.

Intelligent Synergic Control

Synergic MMA.jpg

Getting set up for a weld has never been

faster with our preset synergic programs.



Smart Lift-TIG

Lift TIG.png

The trigger controlled DC Lift Arc ignition allows the arc to be started easily by simply touching the tungsten to the workpiece and lifting it up to start the arc. This stops the tungsten tip sticking to the workpiece and breaking the tip from the tungsten electrode.

 Active Balancing Air Passage

  • Internal airflow is optimally diverged by  a segregation structure.

  • The divergence of airflow can dissipate heat generated by power electronics in a more balanced manner.

  • The power source's overall reliability is improved with the internal structure design.

Energy Saving Smart Fan

smart fan 2.png

The on demand Smart Fan diminishes noise, saves power, helps reduce energy costs, and minimises the number of contaminants being pulled through the machine.

Generator Friendly

AVR Generator.png

The EVO ARC 160 PFC inverter can be used with an AVR  (Automatic Voltage Regulator)  type power generator.

Recommended size is 5 kVA (AC 115V) and 7.5 kVA (AC 230V).

5 year.png

Technical Data


Sales Leaflet PDF

Screenshot 2023-05-31 at 08.43.46.png

Operating Manual PDF

Screenshot 2023-06-01 at 10.48.46.png

MMA Welding Guide PDF

MMA Booklet Image.png
